Expertise and quality of model making at the service of a passion
Slot.it CA16c Chaparral 2E n.65 1st 1st Governor's Trophy & Nassau Tourist Trophy 1966 - Hap Sharp
Reference : CA16c
Description
Driver : Hap Sharp
In 1966 Chaparral introduced model 2E for the Can-Am series. With its high mounted wing, clever aerodynamics and rear mounted radiators, it was the car that changed racing, forever. Its best result was at Laguna Seca, where the 2E of Phil Hill won the race and Jim Hall finished second.
The wing was mounted to the rear suspension uprights to put the downforce directly into the tires without compressing the suspensions. The wing position could be adjusted, with a foot pedal mechanism, from maximum downforce angle for cornering to minimum drag angle for straightaway.
Of all the Chaparrals, this car was Jim Hall's favourite.
This car featured an aluminuium semi-monocoque chassis, and a small block Chevrolet 327 cubic-inch V8 engine.
In 1966, at Nassau, in the 1st Governor's Trophy & Nassau Tourist Trophy, Hap Sharp won the race with this car.
Description of spare parts
Technical sheet
Brand
Chaparral
Race Car Number
65
Race Year
1966
Color
White
System
Analog
Compatible Analog
Yes
Carrera DIGITAL conversion
Slot.it SP43
Scalextric Digital conversion
Slot.it SP15c
Motor mount
Sidewinder
Motor
Slot.it MX16 V12/4 23000 rpm - 170g*cm @12V
Transmission
Rear-wheel-drive (rear 2 wheels)
Gear ratio
11:32 (Pinion 11 teeth - Crown 32 teeth)
Suspension
No
Lighting
No
Magnet
Yes
Length
133 mm
Height
30 mm
Wheelbase
75 mm
Rear Tire
Slot.it PT1120C1
Front Tires
Slot.it PT1121C1
Axle width
48 mm
Weight
63 gr
Scale
1:32
Year of Production
2017
