24
Race Car Number
24
System
Analog
Motor mount
Inline
Transmission
Rear-wheel-drive (rear 2 wheels)
1/32
Scale
1/32
€39.08
Vous cumulez 1.17 € en achetant ce produit
Description
Drivers : Nicola Marozzo, Jean-Pierre Frey and Ranieri Randaccio
The LC2 was created by Lancia to race in the Sport-Prototype category, according to the Group C regulations. It was engaged for the first time in 1983. Designed by Dallara, it was powered by a Ferrari engine, with head derived from 288 GTO; eletronics was highly advanced for that time.
The engine was a 3 liters V8 90°, liquid-cooled, with two turbochargers, that could work at a maximum pressure of 3 bars; the four valves per cylinder were driven by double over head camshaft. The maximum power was 840 hp at 7000 rpm. Both Hewland, 5 gears. The wheels diameter was 15 inches at the front and 17 at the rear. Chassis was made of aluminum and magnesium; body material was carbon fiber composite. The overall weight was 850 kg.
Often, Lancias were as competitive as Porsches, in pure speed, but then suffered troubles at longer distances. The last version of LC2 was raced as a factory car in the late '85 and in the early '86; when Lancia Martini abandoned Endurance races, the car was raced by privateers till 1991. At the 1988 Le Mans 24 Hours, Dollop Racing engaged an LC2 with number 24, with Nicola Marozzo, Jean-Pierre Frey and Ranieri Randaccio at the wheel.
Description des pièces détachées
- Slot.it PI09 Inline Pinions 9 teeth Ø5,5mm x2 €2.92
- Slot.it PT1159C1 Tires 17.2x9.5mm, C1 compound Slick x4 €5.58
- Slot.it PT1167C1 Tires 17.8x10mm, C1 compound Slick x4 €5.33
- Slot.it SP15c Universal Hornby SSD chip €23.25
- Slot.it SP19 Competition Copper Braids 1m €4.58
- Slot.it SP22b Silicon Cables High Flexibility 1m - 23 AWG (0.25mm2) €3.92
- Slot.it SP43 Universal Carrera digital Chip €23.25
- Slot.it W15808215P Plastic Wheels Ø15.8x8.2mm x4 €3.50
- Slot.it W16508215A Hubs Aluminum Ø16,5 x 8,2mm (2 pcs) €6.00
Technical sheet
Brand
Lancia
Race Car Number
24
Color
White
System
Analog
Compatible Analog
Yes
Carrera DIGITAL conversion
Slot.it SP43
Scalextric Digital conversion
Slot.it SP15b
Guide blades type
Slot.it CH66
Motor mount
Inline
Motor
MX06 V12/3 21 500 revolutions/minute
Couple
170 g*cm
Transmission
Rear-wheel-drive (rear 2 wheels)
Gear ratio
9:28 (Pinion 9 teeth - Crown 28 teeth)
Suspension
No
Lighting
No
Magnet
Slot.it CN06
Length
148 mm
Height
30 mm
Wheelbase
84 mm
Rear Tire
Slot.it PT1167C1
Front Tires
Slot.it PT1159C1
Axle width
48 mm
Weight
68 gr
Scale
1/32
